100A RC Watt Meter High Precision Power Analyzer Digital LCD Screen Amp Meter for Voltage(V) Current(A) Power(W) Charge(Ah) and Energy(Wh) Measurement

Description

SPECIFICATIONS:Operates from 4.8-60 V0V with optional auxiliary batteryMeasures 0-200 A, resolution 0.01A;0-60 V, resolution 0.01V;0-6554 W, resolution 0.1W;0-65 Ah, resolution 0.001Ah;0-6554 Wh, resolution 0.01Wh;Functions “Watt Meter” and Power AnalyzerMeasures EIGHT parameters key to electric power safety & performance, Use it to: Prevent peak currents damaging battery. MotorControl, motors, wiring and connectors. Verify sufficient operating voltage under load. Set cutoff voltages, cheek battery capacity &health. Balance battery cells. Confirm proper battery charger operation. Detect receivers and actual operating currentso as to makesure whether an UBEC is needed.DC amp meter power analyzer - automatic detect and continuously display a real-time of Current (A), Voltage (V), Watts (W), Amp-hours (Ah), Watt-hours (Wh), Peak Amps (Ap), Minimum Volts (Vm), Peak Watts (Wp); New alarm function, when the amp is over 150A, the current display will flash to alarmSensitive digital LCD screen display - easy to read the parameter through the clear and bright blue backlight LCD screen; low power consumption of 6 mA, more efficient than any other LED meter.Multifunctional Tester: Evaluate RC battery charging efficiency.Measure power and energy consumption of any battery powered device. Predict model airplane flight time,Choose the best propeller/most efficient motor .Check for wiring and connector power loss.Ensure peak currents are safe for motor, ESC & Battery as well as wiring and connectors.Notice: This watt meter was designed to be safe in systems unsing less than 60V and carrying current up to 100A. DO NOT EXCEED THE LIMITES!
